Trench MOS
Part Number Download Status Circuit Type Process

ESD

Yes/No

VDS

V

VGS

V

ID

A

VGS(TH)

V

RDS(mΩ)@VGS

10V Typ

RDS(mΩ)@VGS

10V Max

RDS(mΩ)@VGS

4.5V Typ

RDS(mΩ)@VGS

4.5V Max

 Package
Reset
Reset All
Active
OK
Reset
Dual-N
Single-N
Single-P
OK
Reset
Planar
Trench
OK
Reset
No
Yes
OK
Reset
OK
Reset
±12
±20
±25
±30
±8
OK
Reset
OK
Reset
-0.3~-1
-0.4~-0.9
-0.4~-1
-1.9
-0.9
-0.9~-2
-1.0~-2.5
-1~-2.1
-1~-2.5
-1~-3
0.35~1.1
0.45~1
0.5~2
0.65~1.2
0.7~1.4
0.8~1.5
1.2~2.8
1.3
1.6
1~2
1~2.5
2~4
OK
Reset
OK
Reset
OK
Reset
OK
Reset
OK
Reset
PDFN3.3×3.3-8L
PDFN5×6-8L
SOT-23
SOT-23-6L
SOT-323
SOT-363
SOT-523
SOT-723
TO-252-2L
OK
Reset
AD-CJ3415
Active
Single-P
 Trench
 Yes
 -20
 ±8
 -4
 -0.3~-1
 -
 -
 37
 50
 SOT-23
AD-CJAB35P03B
Active
Single-P
 Trench
 No
 -30
 ±20
 -35
 -1.0~-2.5
 10.8
 14
 14
 21
 PDFN3.3×3.3-8L
AD-CJL3415
Active
Single-P
 Trench
 Yes
 -20
 ±8
 -4
 -0.3~-1
 -
 -
 37
 50
 SOT-23-6L
AD-CJ2301
Active
Single-P
 Trench
 No
 -20
 ±8
 -2.3
 -0.4~-1
 -
 -
 90
 112
 SOT-23
AD-CJ2305
Active
Single-P
 Trench
 No
 -12
 ±8
 -4.1
 -0.4~-0.9
 -
 -
 30
 45
 SOT-23
AD-CJ2307
Active
Single-P
 Trench
 No
 -30
 ±20
 -2.7
 -1~-3
 73
 88
 110
 138
 SOT-23
AD-CJ4459A
Active
Single-P
 Trench
 No
 -30
 ±20
 -5
 -1~-2.5
 37
 46
 44
 57
 SOT-23
AD-CJ2309A
Active
Single-P
 Trench
 No
 -60
 ±20
 -2
 -1.9
 130
 190
 180
 240
 SOT-23
AD-2N7002DW
Active
Dual-N
 Trench
 No
 60
 ±20
 0.115
 1.6
 1100
 5000
 -
 -
 SOT-363
AD-2SK3018
Active
Single-N
 Trench
 Yes
 30
 ±20
 0.1
 0.8~1.5
 -
 -
 5000
 8000
 SOT-23
AD-2SK3018
Active
Single-N
 Trench
 Yes
 30
 ±20
 0.1
 0.8~1.5
 -
 -
 5000
 8000
 SOT-323
AD-2SK3541
Active
Single-N
 Trench
 Yes
 30
 ±20
 0.1
 0.8~1.5



SOT-723
AD-2N7002KDW
Active
Dual-N
 Trench
 Yes
 60
 ±20
 0.34
 1.3
 900
 2500
 1100
 3000
 SOT-363
AD-BSS84
Active
Single-P
 Trench
 No
 -50
 ±20
 -0.13
 -0.9~-2
 4500
 8000
 -
 -
 SOT-23
AD-CJ3401
Active
Single-P
 Trench
 No
 -30
 ±12
 -4.2
 -0.9
 50
 65
 60
 75
 SOT-23
AD-CJ3407
Active
Single-P
 Trench
 No
 -30
 ±20
 -4.1
 -1~-2.1
 50
 60
 68
 87
 SOT-23
AD-CJAN013P04AL
Active
Single-P
 Trench
 No
 -40
 ±25
 -50
 -1~-2.5
 8.5
 13
 10.5
 18
 PDFN5×6-8L
AD-CJU04N65

Active
Single-N
 Planar
 No
 650
 ±30
 4
 2~4
 2300
 3000
 -
 -
 TO-252-2L
AD-2N7002

Active
Single-N
 Trench
 No
 60
 ±20
 0.115
 1~2.5
 900
 2500
 1100
 3000
 SOT-23
AD-2N7002K

Active
Single-N
 Trench
 Yes
 60
 ±20
 0.34
 1~2.5
 900
 2500
 1100
 3000
 SOT-23
